GF Flutter Animation

Banner image

GFAnimation is a Flutter Animation wherein it makes the UI smooth for the user and the user interaction with the app will be easier. GFAnimation makes it easy to implement a variety of animations.

GF Flutter Animation Type :

1. GF Flutter Rotation Animation

GFAnimation property type: GFAnimationType.rotateTransition , creates a rotation transition for the child of type widget. This type of animation will animate the rotation of a widget.

The below example code shows the Flutter rotation animation.

GF Flutter Rotation Animation

  late AnimationController controller;
  late Animation<double> animation;

  @override
  void initState() {
    super.initState();
    controller =
        AnimationController(duration: const Duration(seconds: 5), vsync: this);
    animation = new CurvedAnimation(parent: controller, curve: Curves.linear);
    controller.repeat();
  }

GestureDetector(
  onTap: () {
    controller.repeat();
  },
  child: GFAnimation(
    turnsAnimation: animation,
    controller: controller,
    type: GFAnimationType.rotateTransition,
    alignment: Alignment.center,
    child: Image.asset(
      'assets image here',
      width: 80,
      height: 80,
    ),
  ),
),

2. GF Flutter Animation Scaling

GFAnimation property type: GFAnimationType.scaleTransition , creates a scale transition for the child of type widget. It animates the scale of a transformed widget. The below code shows the flutter scale animation.

GF Flutter Scaling Animation

  late AnimationController controller;
  late Animation<double> animation;

  @override
  void initState() {
    super.initState();
    controller =
        AnimationController(duration: const Duration(seconds: 5), vsync: this);
    animation = new CurvedAnimation(parent: controller, curve: Curves.linear);
    controller.repeat();
  }

GestureDetector(
  onTap: () {
    controller.repeat();
  },
  child: GFAnimation(
    scaleAnimation: animation,
    controller: controller,
    type: GFAnimationType.scaleTransition,
    child: Image.asset(
      'assets image here',
      width: 80,
      height: 80,
    ),
  ),
),

3. GF Flutter Animation Alignment

GF Flutter Alignment Animation

GFAnimation property type: GFAnimationType.align , creates an alignment transition for the child of type widget. Animates the position alignment of a widget over a given duration whenever alignment changes. The below gives alignment type of animation

GFAnimation(
  duration: Duration(seconds: 2),
  alignment: Alignment.bottomLeft,
  type: GFAnimationType.align,
  child: Image.asset(
    'assets image here',
    width: 80,
    height: 80,
  ),
),

4.GF Flutter Page Slide Transition

GF Flutter Page Slide Transition

GFAnimation property type: GFAnimationType.slideTransition , creates a fractional translation transitions for the child of type widget. Animates the position of a widget relative to its normal position. The below codes shows the example of flutter slide transition example animation.

 late Animation<Offset> offsetAnimation;
  @override
  void initState() {
    super.initState();
    controller =
        AnimationController(duration: const Duration(seconds: 5), vsync: this);
    animation = new CurvedAnimation(parent: controller, curve: Curves.linear);
    controller.repeat();
    offsetAnimation = Tween<Offset>(
      begin: Offset(-5, 0),
      end: const Offset(0, 0),
    ).animate(CurvedAnimation(
      parent: controller,
      curve: Curves.linear,
    ));
  }

Container(
  width: MediaQuery.of(context).size.width,
  child: GFAnimation(
    controller: controller,
    slidePosition: offsetAnimation,
    type: GFAnimationType.slideTransition,
    child: Image.asset(
      'assets image here',
      width: 80,
      height: 80,
    ),
  ),
),

5. GF Flutter Animation Size

Flutter Size Animation

GFAnimation property type: GFAnimationType.size , creates a widget that animates its size. Animates the widget that automatically transitions its size in a given duration whenever the given child's size changes. The example below demonstrates the Text size animation in flutter.

bool selected = false;

late AnimationController controller;
late Animation<double> animation;

@override
  void initState() {
    super.initState();
    controller =
        AnimationController(duration: const Duration(seconds: 5), vsync: this);
    animation = new CurvedAnimation(parent: controller, curve: Curves.linear);
    controller.repeat();
  }

GFAnimation(
  onTap: () {
    if (mounted) {
      setState(() {
        selected = !selected;
      });
    }
  },
  width: selected ? 100 : 50,
  height: selected ? 100 : 50,
  type: GFAnimationType.size,
  controller: controller,
  child: Image.asset(
    'assets image here',
     width: 80,
    height: 80,
  ),
),

6. GF Flutter Animation Container

GF Flutter Animation Container

GFAnimation property type: GFAnimationType.container , creates a widget gives the zooming effect. Animates the widget that automatically zooms in and out in a given duration whenever the given child's size changes. The below example shows the effect of animation.

late AnimationController controller;
late Animation<double> animation;
double _fontSize = 30;

@override
  void initState() {
    super.initState();
    controller =
        AnimationController(duration: const Duration(seconds: 5), vsync: this);
    animation = new CurvedAnimation(parent: controller, curve: Curves.linear);
    controller.repeat();
  }

GFAnimation(
  width: 50,
  changedWidth: 100,
  height: 50,
  changedHeight: 100,
  activeColor: Colors.transparent,
  color: Colors.transparent,
  fontSize: _fontSize,
  type: GFAnimationType.container,
  child: Image.asset(
    'assets image here',
     width: 80,
    height: 80,
  ),
),

GF Flutter Animation Custom Properties

The look and feel of the GFAnimation can be customized using the GFAnimation properties.

NameDescription
durationThe duration for animation to perform
reverseDurationThe duration for reverse animation to perform
alignmentDefines how the animated widget is aligned during Animation.
activeAlignmentDefines how the animated widget is aligned(after the onTap) during Animation.
childThe child of type [Widget] to display animation effect.
curveDetermines the animation curve. Defaults to [Curves.linear].
typetype of [GFAnimation] which takes the type ie, align, size, container, rotateTransition, scaleTransition, slideTransition, and textStyle for the [GFAnimation]
widthdefines [AnimatedContainer] initial width
changedWidthdefines the width of [AnimatedContainer] upto which it can expand during animation
heightdefines [AnimatedContainer] initial height
changedHeightdefines the height of [AnimatedContainer] upto which it can expand during animation
activeColordefines the color of [AnimatedContainer] when onTap triggers
colordefines the color of [AnimatedContainer]
paddingdefines [child]'s or [AnimatedContainer] padding
margindefines [child]'s or [AnimatedContainer] margin
onTapCalled when the user taps the [child]
turnsAnimationFor GFAnimationType.rotateTransition, customized turns animation can be added to [RotationTransition] widget
scaleAnimationFor GFAnimationType.scaleTransition, customized scale animation can be added to [ScaleTransition] widget
controllerType of [AnimationController], its a controller of an animation.
textDirectionDefines direction of the [AnimatedDefaultTextStyle] TextDirection i.e [ltr,rtl]
slidePositionFor GFAnimationType.slideTransition, which animates the position of a widget.
styleDefines the [TextStyle] of [AnimatedDefaultTextStyle]
textAlignDefines the [TextAlign] of [AnimatedDefaultTextStyle]
textOverflowDefines the [TextOverflow] of [AnimatedDefaultTextStyle]
maxLinesDefines the [maxLines] of [AnimatedDefaultTextStyle]
textWidthBasisDefines the [TextWidthBasis] of [AnimatedDefaultTextStyle]
fontSizeDefines the [fontSize] of [AnimatedDefaultTextStyle]
fontWeightDefines the [fontWeight] of [AnimatedDefaultTextStyle]

Last Updated: February 4, 2022
